WPF 마우스 드래그로 길이 표시하는 사각형 그리기

WPF 마우스 드래그로 길이 표시하는 사각형 그리기



마우스 드래그시 사각형을 그리고 사각형 주변으로 길이를 표시합니다.



MainWindow.xaml

<Window x:Class="WpfApp.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        xmlns:local="clr-namespace:WpfApp"
        mc:Ignorable="d"
        Title="MainWindow" Height="450" Width="800" Background="Gray">
    <Grid Background="#01000000">
        <Canvas IsHitTestVisible="False" IsEnabled="False">
            <!-- Rectangle -->
            <ContentControl x:Name="RectAdder" Visibility="Collapsed">
                <ContentControl.ContentTemplate>
                    <DataTemplate>
                        <Grid >
                            <Rectangle
                                x:Name="Rect" SnapsToDevicePixels="True"
                                Fill="#770000FF" Stroke="White" StrokeThickness="1" StrokeDashArray="1 1 1 3" />
                            <!--위쪽-->
                            <Grid x:Name="DrawingHSizeAdorner">
                                <Rectangle
                                    Width="1" Height="15" Fill="White" SnapsToDevicePixels="True"
                                    IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Left" VerticalAlignment="Top" Margin="0,-18,0,0"
                                    Tag="TopLeft"/>
                                <Rectangle
                                    Height="1" Width="{Binding ActualWidth, ElementName=Rect}"
                                    Fill="White" SnapsToDevicePixels="True"
                                    IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Center" VerticalAlignment="Top" Margin="0,-10,0,0"
                                    Tag="TopCenter"/>
                                <Rectangle
                                    Width="1" Height="15" Fill="White" SnapsToDevicePixels="True"
                                    IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Right" VerticalAlignment="Top" Margin="0,-18,0,0"
                                    Tag="TopRight"/>
                                <TextBlock
                                    Text="{Binding ActualWidth, ElementName=Rect, StringFormat='0.00 mm'}" Height="15" Width="{Binding ActualWidth, ElementName=Rect}"
                                    SnapsToDevicePixels="True" IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Center" VerticalAlignment="Top"
                                    TextAlignment="Center" Foreground="White" FontSize="9"
                                    Margin="0,-25,0,0"
                                    ClipToBounds ="True"/>
                            </Grid>
                            <!--아래쪽-->
                            <Grid x:Name="DrawingBHSizeAdorner" >
                                <Rectangle
                                    Width="1" Height="15" Fill="White" SnapsToDevicePixels="True"
                                    IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Left" VerticalAlignment="Bottom"
                                    Margin="0,0,0,-18"
                                    Tag="BottomLeft"/>
                                <Rectangle
                                    Height="1" Width="{Binding ActualWidth, ElementName=Rect}"
                                    Fill="White" SnapsToDevicePixels="True"
                                    IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Center" VerticalAlignment="Bottom" Margin="0,0,0,-10"
                                    Tag="BottomCenter"/>
                                <Rectangle
                                    Width="1" Height="15" Fill="White" SnapsToDevicePixels="True"
                                    IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Right" VerticalAlignment="Bottom" Margin="0,0,0,-18"
                                    Tag="BottomRight"/>
                                <TextBlock
                                    Text="{Binding ActualWidth, ElementName=Rect, StringFormat='0.00 mm'}" Height="15" Width="{Binding ActualWidth, ElementName=Rect}"
                                    SnapsToDevicePixels="True" IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Center" VerticalAlignment="Bottom"
                                    TextAlignment="Center" Foreground="White" FontSize="9"
                                    Margin="0,0,0,-25"
                                    ClipToBounds ="True"/>
                            </Grid>
                            <!--왼쪽-->
                            <Grid x:Name="DrawingLVSizeAdorner" Margin="10,0,0,0">
                                <Rectangle Width="15" Height="1" Fill="White" SnapsToDevicePixels="True"
                                           IsHitTestVisible="False" IsEnabled="False"
                                           HorizontalAlignment="Left"
                                           VerticalAlignment="Top"
                                           Margin="-27,0,0,0"
                                           Tag="LeftTop"/>
                                <Rectangle Height="{Binding ActualHeight, ElementName=Rect}" Width="1" Fill="White" SnapsToDevicePixels="True"
                                           IsHitTestVisible="False" IsEnabled="False"
                                           HorizontalAlignment="Left" VerticalAlignment="Center" Margin="-20,0,0,0"
                                           Tag="LeftCenter"/>
                                <Rectangle Width="15" Height="1" Fill="White" SnapsToDevicePixels="True"
                                           IsHitTestVisible="False" IsEnabled="False"
                                           HorizontalAlignment="Left" VerticalAlignment="Bottom" Margin="-27,0,0,0"
                                           Tag="LeftBottom"/>
                                <StackPanel Margin="-35,70,0,0" HorizontalAlignment="Left" Height="25"
                                            SnapsToDevicePixels="True" IsHitTestVisible="False" IsEnabled="False"
                                            VerticalAlignment="Center">
                                    <StackPanel.RenderTransform>
                                        <RotateTransform Angle="270"/>
                                    </StackPanel.RenderTransform>
                                    <TextBlock Text="{Binding ActualHeight, ElementName=Rect, StringFormat='0.00 mm'}" Height="25" Foreground="White" FontSize="9"/>
                                </StackPanel>
                            </Grid>
                            <!--오른쪽-->
                            <Grid x:Name="DrawingVSizeAdorner" Margin="10,0,0,0">
                                <Rectangle
                                    Width="15" Height="1" Fill="White" SnapsToDevicePixels="True"
                                    IsHitTestVisible="False" IsEnabled="False"
                                    HorizontalAlignment="Right" VerticalAlignment="Top" Margin="0,0,-18,0"
                                    Tag="RightTop"/>
                                <Rectangle Height="{Binding ActualHeight, ElementName=Rect}" Width="1" Fill="White" SnapsToDevicePixels="True"
                                           IsHitTestVisible="False" IsEnabled="False"
                                           HorizontalAlignment="Right" VerticalAlignment="Center" Margin="0,0,-11,0"
                                           Tag="RightCenter"/>
                                <Rectangle Width="15" Height="1" Fill="White" SnapsToDevicePixels="True"
                                           IsHitTestVisible="False" IsEnabled="False"
                                           HorizontalAlignment="Right" VerticalAlignment="Bottom" Margin="0,0,-18,0"
                                           Tag="RightBottom"/>
                                <StackPanel Margin="0,0,-70,0" HorizontalAlignment="Right" Height="25"
                                            SnapsToDevicePixels="True" IsHitTestVisible="False" IsEnabled="False"
                                            VerticalAlignment="Center">
                                    <StackPanel.RenderTransform>
                                        <RotateTransform Angle="90"/>
                                    </StackPanel.RenderTransform>
                                    <TextBlock Text="{Binding ActualHeight, ElementName=Rect, StringFormat='0.00 mm'}" Height="25" Foreground="White" FontSize="9"/>
                                </StackPanel>
                            </Grid>
                            <TextBlock Text="+" HorizontalAlignment="Center" VerticalAlignment="Center" Foreground="White" />
                        </Grid>
                    </DataTemplate>
                </ContentControl.ContentTemplate>
            </ContentControl>
        </Canvas>
    </Grid>
</Window>



MainWindow.xaml.cs

using System;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Input;

namespace WpfApp
{
    /// <summary>
    /// MainWindow.xaml에 대한 상호 작용 논리
    /// </summary>
    public partial class MainWindow : Window
    {
        /// <summary>
        /// 좌측 마우스 클릭 시 포인트 위치입니다.
        /// </summary>
        Point? downPoint;

        /// <summary>
        /// 그려질 사각형입니다.
        /// </summary>
        Rect addRect;

        public MainWindow()
        {
            InitializeComponent();
        }

        /// <summary>
        /// 마우스 좌측 버튼 클릭 시 이벤트입니다.
        /// </summary>
        /// <param name="e"></param>
        protected override void OnMouseLeftButtonDown(MouseButtonEventArgs e)
        {
            var pos = e.GetPosition(this);
            downPoint = pos;

            this.CaptureMouse();
        }

        /// <summary>
        /// 마우스 이동 시 이벤트입니다.
        /// </summary>
        /// <param name="e"></param>
        protected override void OnPreviewMouseMove(MouseEventArgs e)
        {
            base.OnPreviewMouseMove(e);

            if (Mouse.LeftButton == MouseButtonState.Pressed)
            {
                var pos = e.GetPosition(this);

                this.RectAdder.Visibility = Visibility.Visible;

                this.addRect = new Rect(new Point(downPoint.Value.X, downPoint.Value.Y), new Point(pos.X, pos.Y));

                Canvas.SetLeft(this.RectAdder, this.addRect.X);
                Canvas.SetTop(this.RectAdder, this.addRect.Y);
                this.RectAdder.Width = Math.Abs(this.addRect.Width);
                this.RectAdder.Height = Math.Abs(this.addRect.Height);
            }
        }

        /// <summary>
        /// 마우스를 놓을때 발생되는 이벤트입니다.
        /// </summary>
        /// <param name="e"></param>
        protected override void OnMouseUp(MouseButtonEventArgs e)
        {
            this.ReleaseMouseCapture();
        }
    }
}
